Introduction

The SYS Continuous Biomass Carbonization Facility, developed by PelletIndia.com, is an advanced solution for converting wood chips and other biomass into high-value products like biochar, wood vinegar, and syngas. This cutting-edge facility is designed for high efficiency, scalability, and environmental sustainability, making it ideal for industries seeking eco-friendly alternatives to traditional energy sources.

The facility employs modern indirect heating technology and a dual-layer reactor system to ensure maximum thermal efficiency and minimize emissions. The continuous operation of the plant allows for uninterrupted production, making it a vital addition to biomass processing industries that prioritize renewable energy solutions and environmental conservation.

Overview

The SYS Biomass Carbonization Facility represents the next level in biomass conversion technology. The system provides a sustainable pathway for transforming waste biomass, including wood chips, sawdust, and other agricultural residues, into valuable products such as biochar, syngas, and wood vinegar. The plant’s modular design facilitates easy installation, making it highly adaptable to different production scales while optimizing energy utilization and minimizing the environmental footprint.

The carbonization facility operates continuously, with an output capacity ranging from 1 to 3 tons per hour, depending on the model used. With robust components made of 304 stainless steel and PLC-controlled automation, the SYS facility offers superior performance, reliability, and ease of use for biomass processing.

Key Features

• Model: SYS-1000, SYS-3000
• Capacity: 1 TPH to 3 TPH (Ton Per Hour)
• Reactor Material: 304 Stainless Steel
• Heating Method: Indirect Heating
• Fuel for Start: Diesel, Natural Gas, LPG
• Thermal Efficiency: 70% to 90%
• Control System: PLC Automated Control
• Power Requirement: 59.7 KW (SYS-1000), 113 KW (SYS-3000)
• Land Area Required: SYS-1000: 46m x 15m x 6m, SYS-3000: 45m x 15m x 7m
• Labor Requirement: 4-6 workers for 24-hour operation

Advantages

• High Heat Utilization: The dual-layer reactor design ensures efficient heat utilization, minimizing fuel consumption.
• Continuous Operation: The facility operates continuously, offering uninterrupted input and output, leading to high production efficiency.
• Environmental Sustainability: The indirect heating mechanism and syngas recycling significantly reduce emissions, making the process environmentally friendly.
• Modular Design: Easy installation and scalability allow for flexible production setups, suited to various biomass feedstocks and production needs.
• Multi-Product Output: In addition to biochar, the facility produces wood vinegar and syngas, adding economic value through multiple by-products.

Raw Materials

The SYS Biomass Carbonization Facility is designed to process a wide range of biomass materials, including:

• Wood Chips
• Rice Husk
• Sawdust
• Corn Straw
• Sugarcane Bagasse
• Coconut Shell
• Municipal Sludge

Applications

• Biochar: Used as a soil conditioner, for carbon sequestration, and as a reducing agent in the metallurgical industry.
• Wood Vinegar: Applied as an organic pesticide, soil improver, and deodorizer for waste treatment.
• Syngas: Recycled within the facility for heating purposes, reducing the need for external fuel sources.
• Tar: Used in chemical production, such as adhesives and rubber manufacturing.

Unique Aspects

The SYS Biomass Carbonizing System stands out due to its continuous feed mechanism, which allows for maximum productivity with minimal human intervention. Its modular design means that the plant can be adapted to various site conditions, and the use of high-quality stainless steel ensures durability and corrosion resistance.

The facility is designed to optimize energy consumption through an indirect heating system that prevents contamination of biomass while increasing thermal efficiency. Additionally, the recycling of syngas generated during the carbonization process reduces operational costs, making it an economical solution for long-term biomass processing.

Design Focus

The SYS Continuous Carbonization Facility focuses on energy efficiency, ease of use, and environmental protection. It features a double-return heating structure to maximize heat use and avoid direct contact of flue gas with the biomass. This ensures a cleaner process and a consistent quality of biochar, while reducing emissions.

Output Capacity

The SYS Continuous Carbonization Facility has an output capacity of up to 3 tons per hour, depending on the model. It is designed for 24-hour continuous operation, which ensures a consistent supply of high-quality biochar, wood vinegar, and syngas.
